1. Place the machine in a clean and sanitary place with a certain distance from the wall, which is convenient for connecting the tap water and drainage. According to the mark on the machine, connect the tap water pipe to the water inlet pipe of the machine, and connect the outlet of the drainage pipe to the drainage ditch or sewer. Ensure that the connecting pipe from the machine to the drainage ditch is from high to low, so as to prevent the machine from being affected by the accumulated water in the pipe, and discharge the machine feet normally Make the machine smooth.

2、用標準專用氣體軟管將機器的進氣噴嘴連接到氣體減壓閥上，并鎖定喉塞。減壓閥和氣瓶之間的連接需要擰緊，以防漏氣。特別注意:本機使用的減壓閥需要是隨機附帶的低壓閥。

2. Connect the air inlet nozzle of the machine to the gas pressure reducing valve with a standard special gas hose and lock the throat plug. The connection between the pressure reducing valve and the cylinder needs to be tightened to prevent air leakage. Special attention: the pressure reducing valve used in this machine should be the low pressure valve attached with it.

壓減壓閥，禁止使用高、中減壓閥，否則后果自負。

It is forbidden to use high and medium pressure reducing valves, otherwise the consequences will be borne by oneself.

3、電源：220V、50Hz，配備32A漏電保護開關，黃綠雙色線需要牢固接地。

3. Power supply: 220 V, 50 Hz, equipped with 32 a leakage protection switch, yellow and green double color line needs to be firmly grounded.

(二)調試：

（2） Debugging:

1、將石磨豆?jié){機上的料斗拿開，松開磨漿機反搭扣，打開磨蓋檢查上下砂輪是否上緊。

1. Remove the hopper of the stone grinder, loosen the reverse buckle of the grinder, open the grinding cover and check whether the upper and lower grinding wheels are tightened.

2、電動石磨機廠家建議用手轉動濾網架，看看電機轉動是否靈活，蓋上研磨蓋，鎖好搭扣，沿電磨的“粗”方向適當松開研磨蓋上的手柄，攪拌濾網架使其自由轉動(上下砂輪不接觸)，并恢復料斗。

2. The manufacturer of electric stone mill suggests to rotate the filter frame by hand to see if the motor can rotate flexibly, cover the grinding cover, lock the buckle, loosen the handle on the grinding cover along the "rough" direction of the electric mill, stir the filter frame to make it rotate freely (the upper and lower grinding wheels do not contact), and restore the hopper.

3、打開電源，打開磨機開關，電源指示燈亮，啟動電磨機，讓少量自來水進入電磨機，然后慢慢按“精細”方向轉動磨機手柄，直到從出渣口聽到輕微的刮擦聲，然后關閉開關。

3. Turn on the power, turn on the mill switch, the power indicator light is on, start the electric mill, let a small amount of tap water into the electric mill, and then slowly turn the mill handle in the "fine" direction until a slight scraping sound is heard from the slag outlet, and then turn off the switch.

4、逆時針?lè)较蛐_(kāi)水閥，這時會看見水標尺內水位慢慢上升，直到zui高水位時，即按順時針?lè)较蜿P(guān)閉進水閥。

4. Turn the water valve anticlockwise. At this time, the water level in the water gauge will rise slowly. When the water level is high in Zui, close the water inlet valve clockwise.

5、設定好煮奶溫度一般為100℃，打開機內抽風機，開始運轉，風從排煙管吹出。按下點火開關，逆時針旋轉會聽到啪的一聲，然后從火焰觀察孔看到藍色火焰，5秒后慢慢松開點火閥，火焰會正常燃燒。然后關閉點火閥、煮漿開關，完成調試。

5. Set the temperature of boiled milk to 100 ℃, turn on the exhaust fan in the machine, and start to run. The air is blown out from the exhaust pipe. Press the ignition switch and rotate it anticlockwise. You will hear a crack. Then you can see the blue flame from the flame observation hole. After 5 seconds, slowly release the ignition valve and the flame will burn normally. Then turn off the ignition valve and cooking switch to complete the commissioning.

6、以上工作完成后，需要再次檢查各連接是否有泄漏，一切正常便可制作豆奶了。

6. After the completion of the above work, we need to check whether there is leakage in each connection again, and then we can make soy milk if everything is normal.
